Mirror infrared panel heater- MD-Plus Series

Features

  • High quality safet glass mirror surface
  • Easy-Fit bracket for wall mounting
  • Built-in thermostat receiver
  • Wireless controllable by Sundirect smart thermostat

Model Range

ModelPowerSizeWeightMountingHeated Area
MD300-Plus300W60*60cm9Kgwall3-6m²
MD450-Plus450W60*85cm11Kgwall5-9m²
MD650-Plus650W60*120cm17Kgwall7-13m²

Find Out More

The Sundirect MD-Plus series is made from high-quality safety glass mirror combining sophisticated design with optimum heating performance. They do not fog up and provide a dual function being a heater and mirror at the same time.

This mirror infrared heating panel has a silicon wire heating element that has a heat resistance of up to 200° C resulting in increased durability. The heating element is highly isolated making it very safe. The MD-series glass infrared panel heater is insulated with two layers of high-temperature fiberglass for minimum heat loss towards the backside. The polished steel reflector optimizes the heating performance by reflecting the infrared rays to the front.

The MD-Plus series comes with our Easy-Fit mounting solution that ensures easy and secure mounting.

This infrared mirror heater has IP44 protection class, making it suitable to use in bathrooms.

Equipped with our built-in thermostat receiver it can be wireless controlled by our Smart heating control systems. There are three options (sold separately) for operating your panel. Choose from a battery operated controller (Smart2.0), a mains / USB powered controller (Smart2.0Pro) or plug-in thermostat(SmartPlug). Both Smart2.0Pro and Smartplug are controllable via APP and Alexa. You will find the detail information of our smart thermostat under accessory section.

Technical Data:
Model:MD-Plus
Surface:5mm safety glass mirror
BackWhite powder-coated steel
Colour:Super white or black
Heating technology:Silicone heating wire with high-temperature resistant
Infrared radiation6 – 12µm
Warm up time7minutes
Built-in thermostat receiverYes
Transmission frequency433MHz, RF connection
Power supply:220-240V, 50-60Hz
IP rating:IP 44
Protection class:I
Plug:Schuko plug with 1.8 cable
Certifications:CE/ GS/ ROHS/ REACH/ SAA
Warranty5 years

Works With

Smart2.0

Wireless Thermostat

Smart2.0 Pro

Wireless Wifi Thermostat

SmartPlug

WIFI Plug-In Thermostat
